Pyrotec Studio Series top loading kiln

PYROTEC Studio-Line Top-loading Kiln in 10 variants with PY1 or TC66 controller

The STUDIO series from German manufacturer PYROTEC offers a cost-effective kiln solution primarily used in the earthenware sector, i.e., for ceramics with medium firing temperatures. Thanks to insulation specifically tailored to this application, it provides a particularly attractive price-performance ratio. Its lightweight construction also enables firing temperatures of up to 1260 °C (exception: the 230 V models ST 52 H with a max. of 1200 °C and ST 68 H with a max. of 1100 °C).

All models in the STUDIO series are manufactured according to the latest safety standards and come with a corresponding declaration of conformity. PYROTEC also provides a 36-month manufacturer's warranty on its kilns and controllers (excluding heating elements and thermocouples).

What are the differences between the three PYROTEC series: STUDIO, PROFITHERM, and PROFITHERM HS?

The STUDIO series is the budget-friendly entry-level model for hobby potters and is ideal if you are looking for a solid top-loading kiln with a maximum firing temperature of up to 1260 °C (depending on the model). The PROFITHERM series is the higher-performance range for higher temperatures of up to 1320 °C (depending on the model). The PROFITHERM HS models additionally feature a convenient swing lid with gas pressure springs, which makes opening and closing the kiln significantly easier, especially for larger units. Therefore, the PROFITHERM HS models are geared more toward workshops and larger institutions.

The Studio-Line (series) from PYROTEC is available in 10 versions:

Model ST 52 H - 52 liter volume (230 V, max. 1200 °C)
Model ST 52 HD - 52 liter volume
Model ST 68 H - 70 liter volume (230 V, max. 1100 °C)
Model ST 68 HD - 70 liter volume
Model ST 85 HD - 85 liter volume
Model ST 103 HD - 105 liter volume
Model ST 120 HD - 122 liter volume
Model ST 145 HD - 145 liter volume
Model ST 173 HD - 177 liter volume
Model ST 208 HD - 209 liter volume

A detailed comparison of the technical data for the various models can be found in the table next to the product images.

Technical data:

• Temperature measurement with Type S PtRh-Pt thermocouple
• High-quality lightweight firebrick lining
• SUPERWOOL back insulation
• Powder-coated frame
• Stainless steel housing
• Heating elements protected in brick grooves
• Controller connected via plug
• Lid opening over 90°
• Kiln can be locked
• Safety lid switch with forced disconnection
• Over-temperature protection via 2nd safety contactor
• 36-month warranty (heating elements and thermocouples excluded)

Optional accessories:

• Castors: Upon request, the kiln can be supplied with sturdy castors (Ø 75 mm with locking and rim brake). This allows the kiln to be moved comfortably and safely. Direct link: Pyrotec castors for kilns

• Firing Set: Also available as an option is a matching firing set, consisting of cordierite kiln shelves and sillimanite supports. Direct link: Pyrotec kiln shelf set
• Air intake slider in the floor: For better ventilation of the firing chamber, an air intake slider can be integrated to supply the kiln atmosphere with additional oxygen. Direct link: Air intake slider
• Pyrotec firing accessories: A complete list of Pyrotec firing accessories can be found here. Direct link: Firing accessories
• Electronic controllers: An electronic controller (PY1 or TC66) is included as standard:


  • The PY1 controller is manufactured by Pyrotec itself and is a modern compact controller for ceramic kilns that enables precise and reproducible firing processes. The firing curve includes heating up, end temperature, holding time, and natural cooling. Five pre-set programs can be individually adjusted and permanently saved. The controller has a keypad lock to prevent accidents.


  • The TC66 controller from manufacturer Bentrup is a modern compact control system with a fully adjustable firing curve. It allows for a start-up delay as well as two-stage linear heating up to the desired end temperature, followed by holding and controlled cooling. In addition, six pre-set programs are available, which can be individually adjusted.

As a special feature for our Formwerk Berlin customers, we also offer the kiln without a controller at a reduced price. This makes sense for customers who already own a controller. Simply select the "Without controller" option in the menu above. Further compatible controllers are available upon request for more demanding firing programs. Direct link to the full selection: electronic controllers for Pyrotec kilns.
